EVERY TRAIL, EVERY STEEP CLIMB, EVERY THRILLING DESCENT. TESTED AND DEVELOPED BY GIANT’S E-BIKE ENDURO PROS, THIS PROVEN TRAIL RIPPER GIVES YOU THE POWER TO ENJOY THE BEST PARTS OF THE RIDE AGAIN AND AGAIN.
KEY PERFORMANCE FACTORS
Trail technology
Proven Maestro rear suspension (160mm) and a powerful but compact SyncDrive Pro motor technology boost your capabilities on steep climbs and rugged descents. Updated geometry with a shorter rear end and longer reach allow superior handling and agility on technical terrain.
Total control
RideControl Ergo 3 offers integrated, user-friendly button controls that are easy to use. The Giant E-bike App gives you tuning options and E-bike specific fitness tracking.
Long-lasting power
Climb steep mountains and enjoy fun descents all day long with the new downtube-integrated EnergyPak featuring 800Wh of capacity.
| Motor | SyncDrive Pro, 85Nm, powered by Yamaha |
| Controller | RideControl Ergo 3, grip integrated |
| Display | RideControl GO, frame integrated LED display ANT Wireless display compatible |
| Battery | EnergyPak Smart 800Wh EnergyPak Plus range extender compatible |
| Charger | EnergyPak 6A smart charger |
| Sizes | S, M, L, XL |
| Colors | Cordovan/Black |
| Frame | ALUXX SL-grade Aluminium, Advanced Forged Composite Upper Rocker, 160mm Maestro suspension system, flip chip, 12x148mm thru-axle |
| Fork | RockShox ZEB Select 29er, 170mm travel, Charger RC damper, 15x110 Boost, Maxle Stealth, E-bike Approved |
| Shock | Fox Float X Performance, EVOL Large Volume sleeve, 2-position lever, custom tuned |
| Handlebar | Giant Contact Trail, 35mm |
| Grips | Giant Tactal Pro-E, single lock-on |
| Stem | Giant Contact SL 35mm S:40mm, M:50mm, L:50mm, XL:60mm |
| Seatpost | Giant Contact Switch dropper, remote S: 100mm travel / 30.9 x 345mm M: 125mm travel / 30.9 x 395mm L: 150mm travel / 30.9 x 440mm XL: 170mm travel / 30.9 x 450mm |
| Saddle | Giant Romero Trail |
| Pedals | Platform |
| Shifters | Shimano Deore SLX |
| Front Derailleur | MRP HD2 co-moulded chain guide |
| Rear Derailleur | Shimano Deore SLX, 12-speed, Shadow |
| Brakes | Shimano SLX BR-M7120, 4-piston, hydraulic disc, [F] 203mm, [R] 203mm |
| Brake Levers | Shimano SLX, I-spec EV |
| Cassette | Shimano HG-M6100, 10-51T, 12-speed |
| Chain | KMC e.12 Turbo, EcoProteq, e-bike optimised |
| Crankset | Praxis Wave™ 36T Cold Forged 4130 premium steel Praxis e-Cadet custom forged crankarm set S:160mm, M: 160mm, L:165mm, XL:165mm |
| Bottom Bracket | N//A |
| Rims | Giant AM 29"[F] 27.5"[R], Tubeless ready |
| Hubs | Shimano MT410 Boost, Center-Lock |
| Spokes | Sapim E-Lite [R] Race [F], e-bike optimised |
| Tires | Maxxis Minion DHF 29x2.6" foldable, Tubeless, EXO , 3C MaxxTerra[F] Maxxis High Roller II 27.5x2.5" foldable, Tubeless, DoubleDown, 3C MaxxTerra Compound [R] |
| Extras | Tubeless kit (liquid, valves, levers) |
| Lighting | - |
| Lock | Torx 25 Battery Lock with built-in Torque limiter |
| Carrier | - |
| Weight | The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality. |
