Product Details

E220-400M22S is an small module developed independently based on the generation of LoRa TM RF chip LLCC68 produced by Semtech company. LLCC68 is suitable for 433MHz and 470MHz SMD wireless module and uses industrial 32mhz crystal oscillator. Capable of operating in both 433MHz and 470MHz frequency bands, the E220-400M22S is a powerful yet compact wireless module, built with the reliable Semtech LLCC68 LoRa TM chip and a precision 32MHz crystal oscillator.

Brand Name: EBYTE

Origin: Mainland China

Condition: New

Type: Voltage Regulator

Model Number: E220-400M22S

Weight: 1.5g

RF Parameter Value Remark
Working frequency 410~493 MHz -
Transmitting power 22 dBm Max. Power (160mW)
Receiving sensitivity -147 dBm -
Air data rate 0.018k~300kbps -
Test distance 6500m In open and clear air, with maximum power, 5dBi antenna gain, height of 2m
Hardware Parameter Value Remark
Size 14 * 20 mm
Antenna type IPEX / Stamp hole
Communication interface SPI
Package SMD
Electronic parameter Min. Typ. Max. Unit Condition
Power supply 1.8 3.3 3.6 V
Communication level 1.8 3.3 3.6 V
Transmitting current 95 100 105 mA 22dBm(160mW)
Receiving current 6 6.5 7 mA
Sleep current 180 nA
Operating temperature -40 20 85
Operating humidity 10 60 90 %
Storage temperature -40 20 125

Company Profile
Development Testin

EBYTE E220-400M22S LLCC68 LoRa 433Mhz Wireless Module 470Mhz 22dBm 6km Long Range PA LNA RF Receiver Transmitter IPEX Antenna
  • E220400M22S
  • E220400M22SandTX433FPC4516
  • E220400M22SandTX433JKSIPX20

$ 76.49

$ 58.84
